Don’t judge a book by its cover: conserving Essex Illustrated

What does an archive do when faced with a book being torn apart by its own binding? Our Senior Conservator Tony King blogs for us about conserving Essex Illustrated.

In February-March 2012 the Conservation Section at the ERO worked to conserve Essex Illustrated in a Series of Nearly 100 Views, a book of 94 prints dating from 1834. It was in a very poor condition due to the original style of binding and the quality of the materials used during the binding process.

Essex Illustrated, 1834, had clearly seen better days when it arrived in the Conservation Studio

The book contains nearly 100 prints, such as these ones of the ruins of Waltham Abbey and the now demolished Gidea Hall:

This book presented a real challenge; conservation practice is to preserve as much of the original binding as possible and only to rebind a book as a last resort. This is because it is not just the content of a book which can tell us about the past, but the physical object of the book as well.

This book was bound quickly and cheaply, which tells us something about the intended audience and use of the book. Perhaps it was given a cheap binding as the buyer was expected to remove the prints and frame them or put them in a scrap book, and to put what would have been considered an expensive binding on it would alter the nature of the book and the information that can be inferred from its presentation.

Yet to reconstruct the style of binding originally used would seem foolish as it had completely failed; however, to alter the style to a more robust one would not be in-keeping with the historical integrity of the item.

We needed, therefore, to devise a method which would reuse every part of the original binding and preserve the appearance of the book as much as possible whilst creating a strong volume so it could be used by researchers.

Investigation

The first step was to find out how the book had been bound originally. In order to do this, the pages were clamped into a finishing press with the binding removed.

Removing the binding of the book to reveal the stitching underneath

This revealed that the book was made from single sheets of paper that had been oversewn, a sewing style where the stitches are passed through the sheet of paper near the spine edge rather than through the centre of a fold as is more common. Oversewing had been used as there were no folds to sew through as each page was a separate sheet of paper rather than a folded section and it offered the fastest method for sewing the book.

This choice of sewing style made by the original binder was the cause of many of the problems the book now presented. The thick paper used for the prints was restrained by the sewing going through the page and the pages were too stiff to lay flat and articulate properly when the book was opened. This resulted in stress being placed on the pages, causing the paper to tear around the sewing holes and pages to become damaged and loose.

The pages, comprised of single sheets, had been oversewn, and the stitches had torn at the pages

 Furthermore, the style of binding (case bound) combined with the poor quality materials had resulted in a very weak binding with little strength at the point where the boards attached to the book and both boards had torn away and were completely detached.

 Treatment

After washing and deacidifying (treatment of acid present in the paper with an alkaline chemical) each print was adhered at the spine edge to a sheet of thin acid free paper which was then folded around the face of the print to form a folded sheet with a central crease which could be sewn through. These thin sections were sewn together using 5 linen tapes as support which would then be attached to the boards and act as a hinge.

The freshley sewn pages ready for the binding to be reattached

Once sewn, the original boards were reattached by pasting the ends of the linen tapes down underneath the original pastedown, thereby obscuring the new additions to the binding structure. New book cloth was required to replace the partial loss of the original and the bridge the gap created by the increased thickness of the volume.

The fresh linen tapes attached to the back board to act as a hinge



The linen tapes hidden underneath the original pastedown at the back of the book

The conservation work has been carried out without replacing any of the original material or drastically altering the appearance or mechanics of the structure, and following treatment the book is now strong enough to be handled by researchers, without the risk of damage to the binding or the prints inside.

The newly conserved Essex Illustrated, ready and waiting for a new generation of readers

You can see Essex Illustrated for yourself by ordering it in the Searchroom, using the reference LIB/REF 2.

A summer holiday on Essex’s ‘Sunshine Coast’

Where are you planning your summer holiday this year? Essex is possibly not the first place you would think of, but in the nineteenth and early twentieth centuries, Essex’s ‘Sunshine Coast’ was one of the destinations of choice for the discerning British holiday maker.

The historians of the Victoria County History of Essex have been hard at work over the last few years researching the pasts of Clacton, Walton and Frinton, and their research has now been published as volume 11 in the Victoria County History of Essex series.

I/Mb 387/1/4 Print of Walton-on-the-Naze as a seaside village, 1829, just as it was starting to be developed a seaside resort

From the 1820s, Walton and later Clacton and Frinton were promoted as high-class residential and holiday resorts. After a slow start, hampered by poor communications and low demand, growth was stimulated by steam ship companies which landed visitors on newly built piers in Walton and Clacton and by the railways that reached Walton in 1867, Clacton in 1882 and Frinton in 1888.

I/Mb 387/1/13 Photograph showing new resort bulidings at Walton-on-the-Naze constructed c.1860, juxtaposed with the surrounding rural landscape with cows grazing on the cliff tops. Photograph by T. E. Freshwater



I/Mp 86/1/3 Clacton Pier – a key element in the growth of Clactonas a seaside resort, since it enabled steamship to bring visitors to the town

However, the working-class excursionists newly attracted to Clacton, and to a lesser extent Walton, then irrevocably changed the social tone of both resorts. By the 1920s and 1930s Clacton had become a highly commercialized holiday destination and its pier’s funfair-style facilities rivalled those of any other British resort.

   I/Mb 86/1/29 Postcard of the bandstand, Clacton-on-Sea, c.1910

Nearby Jaywick was established as a cheap and cheerful plotland development and Butlins opened its popular Clacton holiday camp in 1938. While Walton remained popular with families, Frinton continued as a ‘select’ resort, with building development and commerce strictly controlled to protect its exclusive character.

After 1945 camping and caravanning increased in popularity, but from the later 1960s the growth of overseas holidays led to a steep decline in the domestic tourism economy. The coast remained popular for retirement and subsequent diversification has led to large dormitory-style housing developments, light industry and shopping centres.

The volume which tells this story is part of a grand tradition: the distinctive big red volumes of the Victoria County Histories have graced the shelves of archives and libraries across England since 1900. Founded in 1899 and dedicated to QueenVictoria, the Histories aim to produce ‘an encyclopaedic record of England’s places and people from earliest times to the present day’. The Histories are still being written by historians working in counties right acrossEngland, and the Essex Record Office is home to the Essex VCH Trust.

Volumes of the Victoria County of History in the ERO Searchroom

Volume 11 of the Victoria County History of Essex, Clacton, Walton and Frinton: North-East Essex Seaside Resorts, will be available in the ERO Searchroom shortly, and can be ordered from Boydell & Brewer Ltd here.

Conservation Surgeries

Do you have family photographs stashed away in a shoebox in the attic? Or perhaps letters, diaries, war records or newspaper cuttings relating to your ancestors?

These documents and pictures help to tell your family’s story, and are irreplaceable. Many things, however, can threaten their survival.

Old photographs, diaries, letters and other documents provide direct windows into your family’s past

Quite apart from the risks of loss and wear and tear, there are the invisible threats that storage in envelopes, boxes and albums can bring. Over time, acid contained within ordinary paper and cardboard will eat away at the documents stored inside.

 The yellowing at the edges of the pages of this self-adhesive album show where acid contained within the paper is seeping out

 This wedding photograph from 1945 has had sellotape applied to it – one of the worst things you can do to an historic photograph or document!

Stored and cared for properly, however, documents like this can last for generations.

To help you keep your documents and photoraphs in the best condition possible the ERO is hosting two Conservation Surgeries. Come along to these free drop-in sessions and bring your documents for expert advice from our Senior Conservator on how best to care for your documents and photographs.



Friday 22 June 2012       10.00am-12.00noon & 1.00pm-4.00pm

At the Saffron Walden Archive Access Point, Saffron Walden Library, King Street, SaffronWalden,CB10 1ES

Thursday 28 June       10.00am-12.30pm & 1.30pm-4.00pm

At the Essex Record Office, Wharf Road, Chelmsford, CM2 6YT



The Robinson photograph and postcard collection

Archivist Allyson Lewis writes about working with the Robinson photograph and postcard collection

This collection consisting of 112 boxes of photograph and postcard albums and slides was compiled by Geoffrey A. Robinson of Thundersley, Essex.  A keen photographer he also collected postcards, chiefly of places in Essex but also all over the country.

One of the 112 boxes of photographs, postcards and prints in the Robinson collection



Just a few of the albums that make up the extensive collection

Mr Robinson had a clear plan when taking his photographs of places in Essex.  He would start with the parish church and take exterior views, then move inside, including any memorials or noteworthy architectural features.  He would then take the churchyard including inscriptions on larger memorials.  Then he would tour the village taking photographs of old buildings, public houses, the school, and any other religious buildings e.g. chapels. He was most active during the 1960s and 1970s and his photographs provide a wonderful window back in time to the quiet lanes of Essex with no cars in sight.

A few of Mr Robinson's photographs of the church at Tilbury-juxta-Clare

One of the more unusual postcards - holes punched in the front of the card allow light to shine through a coloured backing in this night time seaside scene

He put all his photographs and postcards into albums, initially using photograph corners on paper pages but later using the dreaded self-adhesive lift-and-stick plastic pages. These are a particular problem as the adhesive remains sticky and holds the image so firmly to the page that it cannot be removed without damage.  Fortunately, for most of the albums in the Robinson collection the adhesive has dried so much that the photographs and postcards can be removed easily.

Many of the photographs and prints are stuck into damaging self-adhesive albums, and are sometimes very difficult to remove

The images are being been re-stored in inert melinex pockets which will ensure their preservation for years to come.

Postcards and photographs safely re-stored in acid free melinex pockets

Postcards relating to other counties have been sent to the relevant offices (about 40 at the last count!).

One of the mysteries of the collection is the correspondence with a Miss Raverty. The author of the postcards seems to have written to her frequently, and would spread individual messages across several postcards, which were then numbered. We have tried to put the sequences back together, but cannot make much sense of them as yet!

Some of the postcards written to the mysterious Miss Raverty, each containing a fragment of a message



A postcard written to Miss Raverty on 18 November 1902 with a fragment of a message - 'Alfie's place is within thirty yards of this gate of the palace, so he has an excellent view of all the processions & whatever.'

The Robinson photograph and postcard collection is catalogued as Accession A7792 – D/DU 1464

Collections highlight: Southend in historic images

For our second collections post, we thought we would share some highlights from our extensive image collection.

One of our blog’s header images is a picture of Southend-on-Sea, which is probably one of the most photographed places in the county, which given its status as a major Victorian and Edwardian seaside resort is no surprise.

Situated on the mouth of the Thames estuary, Southend first became a resort during the eighteenth century, and tourists have been attracted ever since by its miles of beaches, and later by the longest leisure pier in the world. With its proximity to London and a good rail link, Southend was one of the most popular places for Victorian Londoners to escape to for some sea air. Its popularity declined from the 1960s, however, with the advent of cheap air travel drawing increasing numbers of people abroad for their holidays.

If you would like to find out more about Southend’s past, then you can join our Southend-on-Sea: Stepping Out walk on Friday 18th May, 2.00pm-3.30pm. The walk will trace the history of Southend, from fishing village to Georgian resort to Edwardian London’s playground. The walk costs £5 and advance booking is essential – please telephone 01245 244 620.

I/MB 321/1/32 Black and white print: Marine Parade, Southend J.T. Wood, 278 Strand, London Bound in volume, 'Views of Southend'

I/Mb 321/1/65 Southend from the sea, sailing barge in foreground

I/Mb 321/1/66 View of Pier from the beach, Southend, c.1900

I/Mb 321/1/56 London Tilbury and Southend Railway Poster. Day Excusions to Southend, 1911

I/Mb 321/1/58 Marine Parade, Southend-on-Sea, 1955

I/Mb 321/1/57 Boats at Marine Parade Beach, Southend-on-Sea. Dome of Kursaal in background, c.1955

Our digitisation programme means that many images can now be found on our online catalogue Seax – to search for a digitised image, simply select the ‘Images’ option before you begin your search.

Although many images have been digitised, they still represent a small proportion of our image collections. To search all of our records, simply select ‘Everything’ above the search box. For advice on searching for historic images, you can call us on 01245 244 644.

Work Experience in the Conservation Studio at ERO

Hello readers!

My name is Jillian and I am currently studying on the Masters program in Paper Conservation at Camberwell College. In order to gain more experience and improve my technical skills, I have been undertaking work experience at the ERO, one day a week since July 2011.

Hard at work in the Conservation Studio

During this time I have undertaken a wide variety of projects, from repairing mould-damaged documents, badly damaged photographic material, and architectural drawings, to cleaning parchment and wax seals, and more recently carrying out a large scale map lining using the map wall.

Cleaning a seal

 The photographic project in particular was very interesting as my background is in photography. The photograph in question was torn into several pieces, had missing areas, and had areas of the gelatin emulsion that were folded back on themselves. Treatment for this object included humidification and flattening, stretch lining, infill repairs, gelatin consolidation, and finally housing.

The badly damaged photograph before conservation work

The photograph during the humidification process

The photograph after conservation work was completed

All of the projects I have undertaken so far have helped my technical ability and confidence grow immensely. I have also now experienced first hand specific techniques and treatments that I had previously read or heard about, but had not necessarily been able to carry out at University.

Work experience at the ERO has been, and continues to be, immensely useful and worthwhile, and ERO conservators Tony and Diane, continue to be fantastic in sharing their expertise, and providing advice and support.

If you are interested in finding out more about some of the projects and work I have undertaken, please feel free to have a look at my website.

http://www.jilliangregory.co.uk/

Conservation project: conserving the Takeley deeds

Conservation is a vital part of our work at ERO. Our conservators work to protect and conserve documents, to ensure their survival for years to come.

One recent project has conserved a collection of 42 early medieval deeds relating to the manor of Colchester Hall in Takeley (document references D/DRu T1/1-42). These deeds are special for many reasons; they all date to before 1250, many have intact seals, and notes made in Arabic numerals on the back of the deeds are an early example of the use of this numbering system in England.

In the last line of this note, it is possible to make out an 8 and a 3 – an early example of the use of Arabic numerals in England. The 4 is from a later cataloguing system.

Unusually for such early deeds, over half still have their original seals attached, and the cleaning has made it possible to pick out detail on the seals which had been lost beneath accumulated dirt.

One of the seals half-way through the cleaning process

Tears in the parchment have been repaired using patches of goldbeater’s skin (a membrane made from calves intestine), applied with a gelatine adhesive. The patches are applied with a tissue backing, which is then removed, leaving an invisible repair.

Removing the tissue backing from a parchment repair

The deeds were stored in cramped and damaging conditions, folded up in acidic envelopes, and even in an old manicure set box. The deeds have now been stored flat, with each being treated to its own custom-made board.

A deed in its former storage, folded up in an acidic envelope. Left for long enough the acid in the paper would damage the deed.



A deed in its former storage in an old manicure set box

The newly-conserved deeds are on display for the next three months in our brand-new cases in the Searchroom.

The conservation project was possible thanks to the Newton Bequest, made by Ken Newton, former County Archivist and medieval historian, and his wife Mildred.

The beginning: our oldest document

We thought that a good place to start our new blog was at the ‘beginning’ of our collection, so here Archivist Katharine Schofield introduces the oldest document in our collection.

The oldest document in the ERO is over 1,000 years old. It is an Anglo-Saxon charter (catalogue reference D/DP T209) which dates from 962, in the reign of King Edgar.

(Click for a larger version)

It is a grant of land in South Brent, Devon by King Edgar to one of his ministers Ǽthel[wine]. The land later came into the possession of the Petre family, who originated from Devon and became an important Essex family, and the charter forms part of the extensive Petre collection held at the ERO.

The first part of the charter is written in Latin. The second part which describes the boundaries of the land (e.g. ‘by the lane as far as the earthwork’) is written in Anglo-Saxon.

Unlike medieval deeds this charter is not sealed but has a long list of witnesses, beginning with King Edgar. The witnesses include bishops, ealdormen (royal officials) and ministers and Dunstan (later St. Dunstan), Archbishop of Canterbury.

As this charter is so early in date it does not use the conventional language found in later deeds. It includes the warning to those who might choose to ignore the deed:

But unto any who should lessen or infringe this my grant (far be such a thing from the minds of the faithful) be their portion with those on the other side upon whom is pronounced the sentence ‘Depart from me ye cursed into everlasting fire which was prepared for Satan and his followers’.
